MODULES-Dalian Shipbuilding Offshore Co., Ltd.

No.	Item	Size(m)			Weight（t）
No.	Item	L	B	H	Weight（t）
1	Low-pressure separation module	33	21	32	2445
2	Main compressor B and reinjection module	34	26	40	1415

No.	Item	Size(m)			Weight（t）
No.	Item	L	B	H	Weight（t）
1	Power Module ( L )	30	17.6	14.24	840
2	Power Module ( R )	30	24.68	14.24	1360
3	Heat Medium Module	30	42.2	3.741	606
4	Process Treatment Module I	22	38.2	3.741	502
5	Process Treatment Module II	22	34.2	3.515	485
6	Process Treatment Module III	22	34.2	3.515	544
7	Process Treatment Module IV	27	34.2	3.515	496
8	Process Treatment Module V	26	34.2	3.515	487
9	Flare Tower	35.7	6.47	5.6	25

Item	Size(m)			Weight（t）
Item	L	B	H	Weight（t）
Crude Oil Process Module	30.3	18.545	15.4
Metering Fuel Oil&Water Treatment Module	33.57	18.545	10.4
Start-up Heater Module	13.575	10.735	4.4

No.	Item	Size(m)				Weight（t）
No.	Item		L	B	H	Structure	Assembly
1	Heater medium module	Port side	24.2	20.4	13	128	327
1	Heater medium module	Starboard side	24.2	22	13	133	415
2	Produced water treatment module	Port side	28.7	19	14.8	168	520
2	Produced water treatment module	Starboard side	28.7	19	14.8	182	420
3	Inlet heater module	Port side	23.7	20.4	12.6	179	420
3	Inlet heater module	Starboard side	23.7	20.4	12.6	179	411
4	High pressure separators module	Port side	23.7	20.4	11.2	179	502
4	High pressure separators module	Starboard side	23.7	20.4	11.2	179	522
5	Medium pressure separators module	Port side	23.7	20.4	10	179	404
5	Medium pressure separators module	Starboard side	23.7	20.4	10	179	394
6	Low pressure separators module	Port side	23.7	20.4	11	179	371
6	Low pressure separators module	Starboard	23.7	20.4	11	179	370
7	Power generation module		24.3	44.2	14.5	2074
